Main Technical Parameters
Equipment Outer Dimensions 1000*800*2400mm
Net Weight 200KG
Production Capacity 300-600 bottles/H
Applicable bottles 330ml-2L bottles
Filling stations 4-10
Power Supply Voltage AC 380V 50HZ (customized)
Main function and feature
1、All procedures are thoroughly controlled by SIEMENS programmable controller. All parameters (time values) can be adjusted and shown through touch screen without stopping the machine.
2、All use pneumatic double acting Angle seat valve which could ensure the action sensitivity and reliability
3、Adopt isobar filling method and with unique pressure maintaining system，performance stable and reliable, beer loss minimum.
4、With pressure compensator, to guarantee a stable filling process.
Fix the bottles--purge-- filling-- pressure stabilization--pressure relief--take the bottles
